JSD3528
S mount lens ultra wide angle lens large aperture
PN: JSD3528
F2.4
HFOV 89° 82°
TTL 22mm
Thread M12
Distortion <3.9% <4%
Image Sensor 1/2.5" 1/2.8"
- Information
- Related Products
Description
The JSD3528 is designed for 1/2.5” image format with HFOV 89 degree on Sony IMX317. Have 650nm IRCF, 850nm IRCF and 940nm IRCF version, good choice for drone and robotic application.
Application
l Aerial Image
l Robotics
l Wearable Camera
l Video Conference Camera
Specification
|
| |
Model | JSD3528 | |
Image sensor | 1/2.5” CMOS | |
Image Circle | 8 mm | |
Resolution | 12MP | |
Focal Length | 3.14mm | |
Aperture | F/2.4 | |
TTL | 22mm | |
FOV | DFOV100° HFOV89° VFOV57° | |
Distortion | 1.2% | |
