JSD3428
S mount lens wide angle lens large aperture
model： JSD3428
image sensor: 1/2.5"
Distortion: 0.3%
HFOV 80° on 5mp 1/2.5" sensor
Max image circle 8mm support up to 1/2.7"
- Information
- Related Products
Description
The 3.6mm M12 lens is designed for face recognition, no distortion with HFOV 80° on 1/2.5" sensor.
Specification
|
|
| |
Model | JSD3428 | |
Image sensor | 1/2.5” CMOS | |
Image Circle | 8mm | |
Resolution | 5MP | |
Focal Length | 3.6mm | |
Aperture | F2.8 | |
TTL | 19mm | |
FOV | DFOV 96° HFOV 80° VFOV 65° | |
Distortion | 0.3% | |
