50MP Ultra HD Large Format Lens JSD5042 126° DFOV 1/1.55" M16 Mount 4G4P Lens for OmniVision OV50E40

JSD5042: 50MP Ultra-High Resolution | 1/1.55" Large Format Compatibility | M16 Industrial Interface

Breaking Imaging Bottlenecks: A 126° Wide-Angle Optical Solution Tailored for 50MP Sensors

Key Features

Extreme Resolution: Perfectly matched with the OmniVision OV50E40 to fully unleash the potential of every single pixel on a 50MP sensor.

Large Format Coverage: Supports 1/1.55" image sensors, delivering superior signal-to-noise ratio (SNR) and low-light performance compared to conventional lenses.

4G4P Hybrid Structure: Combines the thermal stability of glass with the high precision of aspherical plastic, achieving an optimal balance between lightweight design and high performance.

[ Request Technical Whitepaper / Inquire for Bulk Pricing ]

1/1.55" Large Format Design for Superior Image Quality

Compared to standard 1/2.3" or 1/3" lenses, the JSD5042 features a significantly larger effective optical area. This allows it to capture more photons under identical lighting conditions, boosting dynamic range and making it the premier choice for high-performance drones and high-end surveillance systems.

50MP Resolution: Capturing Every Detail

The optical path is precisely calibrated for 50-megapixel sensors, achieving an exceptionally high center MTF. From edge-to-edge sharpness to center clarity, it satisfies the strict demands of high-precision industrial vision inspection and AI recognition for absolute clarity.

126° DFOV Wide-Angle Vision

While providing an expansive field of view, the precise 4G4P optical structure keeps distortion strictly under control (< -10.30%). This minimizes pixel loss typically caused by post-processing algorithmic corrections, delivering more natural images for video conferencing and smart home applications.

Target Applications

High-End Drone Aerial Photography: Lightweight design paired with 50MP high resolution empowers surveying, mapping, and professional photography.

4K/8K Video Conferencing: Optimized for large sensors to maintain clean, crisp imagery even in low-light meeting rooms.

Smart Home / Visual Doorbells: A 126° wide-angle view covers expansive doorstep areas, while 50MP clarity ensures flawless facial recognition.

Industrial Machine Vision: Engineered for precision part inspection and large-scale monitoring, delivering lab-grade imaging consistency.

Technical Specifications

Why Choose JSD5042? (Engineering Trust)

M16 Reinforced Mount: Compared to standard M12 mounts, the M16 interface provides a larger light aperture and superior structural stability, making it perfectly suited to support the heavier lens groups required for 1/1.55" large-format sensors.

Precision Manufacturing: Produced in a 3,000-square-meter dust-free cleanroom and verified by automated MTF testing equipment, ensuring every single lens shipped meets strict 50MP resolution standards.

Deep Sensor Optimization: Explicitly calibrated to match the Chief Ray Angle (CRA) of the OmniVision OV50E40, effectively eliminating edge color shifting and vignetting issues common to large-format sensors.

FAQ (Engineering Consultation)

Q: Can this lens be used on an M12 mount base?

A: No. Due to the large 1/1.55" sensor format, an M16 interface is mandatory to prevent image cropping, vignetting, and degradation of optical performance.

Q: How stable is the 4G4P structure under high temperatures?
