2MP M8 Mount Mini Lens JSD2635 7.04mm Ultra Short TTL

PN: JSD2635
FOV 66 degree
M8 and M12 available
TTL: 7.04mm

: 5MP 1/2.7" Wide Angle Lens JSD2828, 105° DFOV M12
PN: JSD2828
HFOV 94°
Max image circle 6.8mm
TTL 13.5mm
Dis: 1.5%

: 2MP 160° Ultra Wide Angle Lens JSD1526 1/2.7" M12
PN: JSD1526
F2.7
HFOV 125°
TTL 11.4mm
Thread M12
Distortion <-14%
Image Sensor 1/2.7"

: 3MP 5G Full Glass Wide Angle Lens JSD3135 140° DFOV 1/2.7" M12
PN: JSD3135
HFOV 114°
Max image circle 7mm
Operating temperature from 20℃ to 85℃

: 2MP M8/M9/M12 Mount Compatible Lens JSD3420 8.61mm Ultra Short TTL
PN: JSD3420
HFOV 65°
TTL 8.6mm
Distortion 0.5%
M8 and M12 version available

: 5MP 92° Wide Angle Low Distortion <0.95% Lens JSD3427 1/2.7" M12
PN: JSD3427
HFOV 80°
TTL 15.6mm
Image Circle 7.2mm

: 4MP 103° Wide Angle Lens JSD3429 1/2.7" M10/M12
PN: JSD3429
F2.8
Max image circle 7mm
HFOV 94°
TTL 15.6mm

: 5MP 71° DFOV Low Distortion <0.52% Lens JSD3523 1/2.7" M12
PN: JSD3523
EFL 4.5mm
HFOV 64°
Distortion 0.5%
1/2.7" format
TTL 14mm

: 5MP F2.0 Large Aperture Industrial Lens JSD3920 1/2.7" M12
PN: JSD3920
Aperture F2.0
HFOV 80° on 1/2.7" sensor
Distortion: <1%

: 3MP F1.8 Large Aperture 6G Full Glass Lens JSD3023 154° Ultra Wide Angle 1/2.7" M12
PN: JSD3023
F1.8
HFOV 114° 126°
TTL 16.2mm
Thread M12
Distortion <-16.2%
Image Sensor 1/2.7" 1/2.9"

: Low Distortion <0.5% Lens JSD3921 1/2.7" M12 Mount 4.5mm EFL Camera Lens for onsemi AR0230
PN: JSD3921
HFOV 65°
Max image circle 6.8mm
TTL 22mm
Distortion: 0.3%

: 5MP 97° DFOV Low Distortion <0.8% Lens JSD3922 1/2.7" M12
PN: JSD3922
HFOV 89°
Distortion 0.8%
IR correction
TTL 17mm

Total30Records«Prev 123 Next»
