Breaking Vision Limits: An In-Depth Look at the JSD2022 8MP Ultra-HD Wide-Angle Lens
In sectors like intelligent security, automotive smart cabins, drone vision, and industrial inspection, finding the perfect balance between wide-angle coverage, high resolution, and low distortion has always been a major engineering challenge.
Today, we are breaking down a standout performer in the optical market—the JSD2022. Packed with an 8MP ultra-high-definition resolution and a wide-field design, this lens is rapidly becoming the go-to standard for next-generation smart vision hardware.
Key Advantages: Why the JSD2022 is the Industry Choice
1. 8MP Retina-Level Resolution for Sharp Detail Capture
Specifically engineered for 1/2.8" large-format sensors, the JSD2022 supports up to 8MP ultra-HD resolution. Whether capturing facial features in long-range surveillance or mapping ground textures during drone flights, it delivers crisp, razor-sharp imagery right to the edges—providing high-quality, raw data optimized for backend AI recognition algorithms.
2. 118° Ultra-Wide Field of View to Eliminate Blind Spots
The JSD2022 offers exceptional spatial capture capabilities within a highly compact form factor:
DFOV (Diagonal FOV): 118°
HFOV (Horizontal FOV): 109°
VFOV (Vertical FOV): 75°
A horizontal field of view exceeding 100° means a single camera can cover a massive area. This significantly reduces the number of cameras required for deployment, lowering overall system costs.
3. ＜-2% Ultra-Low Distortion for True-to-Life Imaging
The most common flaw in standard wide-angle lenses is "barrel distortion" (where the edges of the image stretch and warp). The JSD2022 aggressively controls optical distortion to under -2%. This near-zero distortion performance makes it irreplaceable in scenarios demanding strict geometric accuracy, such as dashcams, 360° surround-view systems, and industrial metrology.
4. 1G5P Hybrid Structure: Balancing Performance and ROI
The lens utilizes a cutting-edge 1 Glass + 5 Plastic (1G5P) hybrid optical design.
The Glass Element is placed on the outermost layer, offering superior weather resistance, high light transmission, and robust protection against scratches and environmental aging.
The Plastic Elements leverage complex aspherical designs to precisely correct optical aberrations while significantly optimizing total weight and mass-production costs.
Core Specifications at a Glance
Parameter | Specification | Business Value |
Model | JSD2022 | Industry-standard model with a mature supply chain. |
Effective Focal Length (EFL) | 2 mm | Ultra-short focal length, foundational for wide-angle performance. |
Max Aperture (F/NO) | 2.0 | Large aperture ensuring ample light intake for low-light and night vision. |
Resolution | 8 MP | Fully meets 4K ultra-HD imaging requirements. |
Total Track Length (TTL) | 15.6 mm | Highly compact structure, easily embedded into low-profile devices. |
Mount Thread | M80.35 / M120.5P | Dual thread options available for seamless compatibility with mainstream modules. |
arget Applications
Smart Security & Smart Home: 4K access control terminals, ultra-HD panoramic surveillance, and smart video doorbells.
Automotive Vision (ADAS & DMS): In-cabin occupant monitoring, dashcams, and rearview backup cameras.
Robotics & UAVs: VSLAM vision navigation for robotic vacuums and obstacle avoidance for drones.
Video Conferencing: Wide-angle, distortion-free video capture for huddle rooms and small meeting spaces.
The JSD2022 is more than just a spec-heavy lens; it is a mature, commercial-grade imaging solution. By packing 8MP clarity, a 118° field of view, and ＜-2% distortion into a compact 15.6mm footprint (TTL), it delivers the exact competitive edge needed to fast-track your hardware project to market.
Inquiries & Sample Requests
We offer both M8 and M12 thread options for customization and bulk supply. To request the full datasheet, get a quote, or secure samples for testing, please contact our sales team directly or leave a message below.
